SARSA

Figure: SARSA algorithm pseudocode ¹

toyrl.sarsa.default_config module-attribute

default_config = SarsaConfig(env_name='CartPole-v1', render_mode=None, solved_threshold=475.0, max_training_steps=2000000, learning_rate=0.01, log_wandb=True)

toyrl.sarsa.trainer module-attribute

trainer = SarsaTrainer(default_config)

toyrl.sarsa.SarsaConfig dataclass

SarsaConfig(env_name: str = 'CartPole-v1', render_mode: str | None = None, solved_threshold: float = 475.0, gamma: float = 0.999, max_training_steps: int = 500000, learning_rate: float = 0.00025, log_wandb: bool = False)

Configuration for SARSA algorithm.

env_name class-attribute instance-attribute

env_name: str = 'CartPole-v1'

render_mode class-attribute instance-attribute

render_mode: str | None = None

solved_threshold class-attribute instance-attribute

solved_threshold: float = 475.0

gamma class-attribute instance-attribute

gamma: float = 0.999

max_training_steps class-attribute instance-attribute

max_training_steps: int = 500000

The maximum number of environment steps to train for.

learning_rate class-attribute instance-attribute

learning_rate: float = 0.00025

The learning rate for the optimizer.

log_wandb class-attribute instance-attribute

log_wandb: bool = False

Whether to log the training process to Weights and Biases.

toyrl.sarsa.PolicyNet

PolicyNet(env_dim: int, action_num: int)

Bases: Module

Source code in toyrl/sarsa.py

def __init__(
    self,
    env_dim: int,
    action_num: int,
) -> None:
    super().__init__()
    self.env_dim = env_dim
    self.action_num = action_num

    layers = [
        nn.Linear(self.env_dim, 128),
        nn.ReLU(),
        nn.Linear(128, self.action_num),
    ]
    self.model = nn.Sequential(*layers)

env_dim instance-attribute

env_dim = env_dim

action_num instance-attribute

action_num = action_num

model instance-attribute

model = Sequential(*layers)

forward

forward(x: Tensor) -> Tensor

Source code in toyrl/sarsa.py

def forward(self, x: torch.Tensor) -> torch.Tensor:
    return self.model(x)

toyrl.sarsa.Experience dataclass

Experience(terminated: bool, truncated: bool, observation: Any, action: Any, reward: float, next_observation: Any = None, next_action: Any = None)

terminated instance-attribute

terminated: bool

truncated instance-attribute

truncated: bool

observation instance-attribute

observation: Any

action instance-attribute

action: Any

reward instance-attribute

reward: float

next_observation class-attribute instance-attribute

next_observation: Any = None

next_action class-attribute instance-attribute

next_action: Any = None

toyrl.sarsa.ReplayBuffer dataclass

ReplayBuffer(buffer: list[Experience] = list())

buffer class-attribute instance-attribute

buffer: list[Experience] = field(default_factory=list)

__len__

__len__() -> int

Source code in toyrl/sarsa.py

def __len__(self) -> int:
    return len(self.buffer)

add_experience

add_experience(experience: Experience) -> None

Source code in toyrl/sarsa.py

def add_experience(self, experience: Experience) -> None:
    self.buffer.append(experience)

reset

reset() -> None

Source code in toyrl/sarsa.py

def reset(self) -> None:
    self.buffer = []

sample

sample(with_next_sa: bool = True) -> list[Experience]

Source code in toyrl/sarsa.py

def sample(self, with_next_sa: bool = True) -> list[Experience]:
    if with_next_sa is False:
        return self.buffer
    else:
        res = []
        for i in range(len(self.buffer) - 1):
            experience = self.buffer[i]
            next_experience = self.buffer[i + 1]
            res.append(
                Experience(
                    observation=experience.observation,
                    action=experience.action,
                    reward=experience.reward,
                    next_observation=next_experience.observation,
                    next_action=next_experience.action,
                    terminated=next_experience.terminated,
                    truncated=next_experience.truncated,
                )
            )
        return res

toyrl.sarsa.Agent

Agent(policy_net: PolicyNet, optimizer: Optimizer)

Source code in toyrl/sarsa.py

def __init__(self, policy_net: PolicyNet, optimizer: torch.optim.Optimizer) -> None:
    self._policy_net = policy_net
    self._optimizer = optimizer
    self._replay_buffer = ReplayBuffer()
    self._action_num = policy_net.action_num

onpolicy_reset

onpolicy_reset() -> None

Source code in toyrl/sarsa.py

def onpolicy_reset(self) -> None:
    self._replay_buffer.reset()

add_experience

add_experience(experience: Experience) -> None

Source code in toyrl/sarsa.py

def add_experience(self, experience: Experience) -> None:
    self._replay_buffer.add_experience(experience)

act

act(observation: floating, epsilon: float) -> int

Source code in toyrl/sarsa.py

def act(self, observation: np.floating, epsilon: float) -> int:
    if np.random.rand() < epsilon:
        action = np.random.randint(self._action_num)
        return action
    x = torch.from_numpy(observation.astype(np.float32))
    with torch.no_grad():
        logits = self._policy_net(x)
    action = int(torch.argmax(logits).item())
    return action

policy_update

policy_update(gamma: float) -> float

Source code in toyrl/sarsa.py

def policy_update(self, gamma: float) -> float:
    experiences = self._replay_buffer.sample()

    observations = torch.tensor([experience.observation for experience in experiences])
    actions = torch.tensor([experience.action for experience in experiences], dtype=torch.float32)
    next_observations = torch.tensor([experience.next_observation for experience in experiences])
    next_actions = torch.tensor([experience.next_action for experience in experiences])
    rewards = torch.tensor([experience.reward for experience in experiences])
    terminated = torch.tensor(
        [experience.terminated for experience in experiences],
        dtype=torch.float32,
    )

    # q preds
    action_q_preds = self._policy_net(observations).gather(1, actions.long().unsqueeze(1)).squeeze(1)
    with torch.no_grad():
        next_action_q_preds = self._policy_net(next_observations).gather(1, next_actions.unsqueeze(1)).squeeze(1)
        q_targets = rewards + gamma * (1 - terminated) * next_action_q_preds
    loss = torch.nn.functional.mse_loss(action_q_preds, q_targets)
    # update
    self._optimizer.zero_grad()
    loss.backward()
    # clip grad
    torch.nn.utils.clip_grad_norm_(self._policy_net.parameters(), max_norm=1.0)
    self._optimizer.step()
    return loss.item()

toyrl.sarsa.SarsaTrainer

SarsaTrainer(config: SarsaConfig)

Source code in toyrl/sarsa.py

def __init__(self, config: SarsaConfig) -> None:
    self.config = config
    self.env = self._make_env()
    if isinstance(self.env.action_space, gym.spaces.Discrete) is False:
        raise ValueError("Only discrete action space is supported.")
    env_dim = self.env.observation_space.shape[0]
    action_num = self.env.action_space.n
    policy_net = PolicyNet(env_dim=env_dim, action_num=action_num)
    optimizer = optim.Adam(policy_net.parameters(), lr=config.learning_rate)
    self.agent = Agent(policy_net=policy_net, optimizer=optimizer)

    self.gamma = config.gamma
    self.solved_threshold = config.solved_threshold
    if config.log_wandb:
        wandb.init(
            # set the wandb project where this run will be logged
            project="SARSA",
            name=f"[{config.env_name}],lr={config.learning_rate}",
            # track hyperparameters and run metadata
            config=asdict(config),
        )

config instance-attribute

config = config

env instance-attribute

env = _make_env()

agent instance-attribute

agent = Agent(policy_net=policy_net, optimizer=optimizer)

gamma instance-attribute

gamma = gamma

solved_threshold instance-attribute

solved_threshold = solved_threshold

train

train() -> None

Source code in toyrl/sarsa.py

def train(self) -> None:
    epsilon = 1.0
    global_step = 0

    observation, _ = self.env.reset()
    while global_step < self.config.max_training_steps:
        global_step += 1
        epsilon = max(0.05, epsilon * 0.9999)

        action = self.agent.act(observation, epsilon)
        next_observation, reward, terminated, truncated, info = self.env.step(action)
        experience = Experience(
            observation=observation,
            action=action,
            reward=float(reward),
            next_observation=next_observation,
            terminated=terminated,
            truncated=truncated,
        )
        self.agent.add_experience(experience)
        observation = next_observation
        if self.env.render_mode is not None:
            self.env.render()

        if terminated or truncated:
            if info and "episode" in info:
                episode_reward = info["episode"]["r"]
                loss = self.agent.policy_update(gamma=self.gamma)
                self.agent.onpolicy_reset()
                print(
                    f"global_step={global_step}, epsilon={epsilon}, episodic_return={episode_reward}, loss={loss}"
                )
                if self.config.log_wandb:
                    wandb.log(
                        {
                            "global_step": global_step,
                            "episode_reward": episode_reward,
                            "loss": loss,
                        }
                    )

---

1. L. Graesser and W. L. Keng, Foundations of deep reinforcement learning: Theory and practice in python. Addison-Wesley Professional, 2019. ↩
